Multi Input Bridge (MIB)

## What is Multi Input Bridge (MIB)?

MIB is a software-based KVM solution that allows you to control

between two and four Windows PCs using a single mouse and keyboard.

Simply move your mouse cursor to the edge of the screen

to switch control to the adjacent PC.

You can seamlessly share the clipboard and files,

use drag-and-drop, and even share screens—

making multiple computers feel like one.

No dedicated hardware switch (physical KVM) or cloud service is required;

it connects your PCs over the same LAN (or VPN)

using software alone.

It is a portable, folder-based application that requires no installation.

"Work on your main PC while

controlling a nearby mini-PC or laptop with the same mouse."

We created this tool to deliver an experience where

"all the PCs on your desk become one."

## Key Features

🖱️ **Mouse/Keyboard Sharing**

— Switch control to another PC simply by moving the cursor past the screen edge.

PCs can be arranged in any layout (top, bottom, left, or right).

🧭 **Mesh Connection for 2–4 PCs**

— Connect three or more PCs simultaneously

and control any of them directly from your current station

(no master/slave hierarchy; all PCs are equal peers).

🤝 **Neutral Standby Mode**

— Connect two PCs as equals;

whichever one moves the mouse becomes the "driver."Ideal for side-by-side workstations

📋 **Shared Clipboard**

— Copy text or images

and paste them directly onto the other PC

📁 **File/Folder Transfer**

— Transfer via copy-paste or by

dragging and dropping across screens

Supports "Cut" (move) operations

🖥️ **Screen Sharing**

— View the other PC's screen on your own

Operate headless PCs or laptops with the lid closed

(High-speed performance via differential transfer)

🔒 **Encrypted Communication**

— Set a "connection password" to

encrypt all communications

(ChaCha20-Poly1305)

🛠️ **Administrator Window Control**

— Use the "Elevation Helper" to

control windows requiring administrator privileges on the other PC.

## For Peace of Mind (Privacy & Security)

As this app handles user input and screen data,

the following design considerations have been implemented:

**Passwords are not transmitted over the network**

(Challenge-response authentication)

Setting a password encrypts all communications.

**No logs of typed text, passwords, or clipboard contents are kept** (only activity records such as operation counts)

**No cloud relay**

Communication takes place directly between your PCs.

⚠️ Please use only on PCs you manage

and have authorized permission to access.

Do not use to control third-party PCs without authorization.

⚠️ Due to the nature of handling input and screen data,

antivirus software may trigger a warning.

Please grant permission if necessary to use the app.

## System Requirements

**Two or more** PCs running Windows 10 / 11 (64-bit)

Same LAN (wired connection recommended); uses one TCP port (default: 45800)

Also works over VPN.No installation required (simply place the folder).

Running as administrator is not required.

## How to Use (3 Simple Steps)

1. Extract the downloaded ZIP file and

copy the entire folder to each PC you wish to connect.

2. Launch `Multi_Input_Bridge.exe` on each PC.

3. Enter connection settings (target IP address and password) and click "Connect."

After that, simply move your mouse to the edge of the screen.

Please refer to the included README file for detailed settings and features.

## Known Limitations

For security reasons, the current version cannot remotely control

Windows login screens, lock screens, or UAC (administrator confirmation) prompts.

→ For unattended operation, we recommend using this alongside auto-login.

(Instructions are provided in the README.)

*We plan to address this in the upcoming "Full Version."

This software targets the main monitor (single screen) of each PC.

# 【Pricing & Support】

This version (v1.9.0) is distributed for free.

We want as many people as possible to use it

and help us improve it through your feedback.

If you enjoy using it, your support would mean the world to us 🙏

Any support received will go toward further development and

realizing the upcoming **Full Version v2.0.0**

**(a SYSTEM service version capable of remote control even at the login screen).**

> We plan to offer the Full Version v2.0.0 as a paid product

(tentatively priced at a few hundred yen) upon completion.

> If you like the free version,

please show your support and follow us for future updates.

# 【Support & Inquiries】

X (formerly Twitter): @FantaMiraGirlsR

We welcome bug reports and feature requests.

We will address and improve the software to the best of our ability.

# 【License】

Please use this software only after agreeing to

the included End User License Agreement (EULA.txt).

This software is intended for personal use. Please use this software solely for your own personal use

(use for your own work-related tasks is permitted).

Due to the nature of the application, you may copy and use it across multiple PCs that you personally use.

Please refrain from redistribution or resale

(distribution to third parties, deployment within an organization, incorporation into other products, etc., is not permitted).

This software includes third-party open-source software

(such as Qt/PySide6);

details regarding the respective licenses are provided in the included

**THIRD_PARTY_LICENSES.txt** file.

Please refer to the included EULA for further details.

Created by: FMGX_AI

# [Update History]

- v1.9.0 Public release (Japanese)

- v1.9.1 Added features to screen sharing

- v1.10.0 Multilingual support (Japanese, English, Spanish)

- v1.10.1 Multilingual support (German)

- v1.10.2 Multilingual support (Portuguese, French, Italian)
